Most microwave calls here are over-the-range units, which are part cooker and part extractor and are fitted into the cabinet run above the range. That fitting is half the job. The other half is that a microwave holds a dangerous charge after it is unplugged, which is the one appliance in the kitchen we would ask you not to open.

Turntable turns, food stays cold

The cavity light and the fan run off the low-voltage side, so a microwave that looks alive but heats nothing has failed on the high-voltage side. In practice that is the magnetron, the high-voltage diode, or the capacitor, and less often the transformer. We test the circuit rather than guessing, because a diode is a modest part and a magnetron is not. On an older over-the-range unit, a failed magnetron is often the point where a new microwave is the better answer, and we will say so.

Dead display, or nothing happens on start

Three door interlock switches sit behind the latch on most units, wired so that a door left ajar cannot let the magnetron run. When one fails out of sequence it blows the line fuse instantly, and the microwave goes completely dark. Replacing the fuse alone puts you back where you started within days. The other common cause of a dead panel is the membrane keypad, where the traces wear through and one row stops responding before the rest. A control board failure is possible but less common than either.

Diagnosis

What usually fails, and how you tell

Failed magnetron

How it showsRuns a full cycle, turntable moves, food is cold.

The repairTest the high-voltage circuit first; replace the magnetron only if diode and capacitor are sound.

Open high-voltage diode

How it showsNo heat, sometimes with a buzz or a hum under load.

The repairReplace the diode and check the capacitor before running the oven again.

Door interlock switch out of sequence

How it showsDead unit and a blown line fuse, often after the door was slammed.

The repairReplace the switch set and adjust the latch so the sequence closes cleanly.

Burnt waveguide cover

How it showsSparking inside the cavity and a smell of scorching.

The repairFit a new cover and degrease the cavity; check the waveguide behind it for damage.

Worn membrane keypad

How it showsOne row of buttons does nothing, the rest respond normally.

The repairReplace the touch panel; the control board is usually fine.

Failed door latch hook

How it showsDoor will not stay shut, or has to be pressed in to start a cycle.

The repairReplace the latch assembly, and check the switches it operates for damage.

Arcing, sparks and a burnt smell

Arcing almost always starts at the waveguide cover, the small mica panel on the cavity wall. Grease soaks into it, chars, and then burns in a spot that spreads each time the oven runs. Caught early it is a cheap part and a clean. Left long enough it burns through into the waveguide itself and takes the magnetron with it. Metal trim on a dish, a bent rack or a chipped cavity coating cause the same sparking, so we check what has been going in the oven as well as the oven itself. Stop using it until it is looked at.

Getting an over-the-range unit down

These hang on a wall bracket with bolts up through the cabinet floor, and they are heavier than they look. Taking one down is a two-person job, and the cabinet above usually has to be emptied first. Most repairs need it down: the fuse, the interlocks and the high-voltage components are all behind panels you cannot reach in place. In a rental or a condo it is worth checking whether the microwave vents outside or recirculates through a charcoal filter, because a unit that has been recirculating for years is often full of grease before anything electrical failed.

Microwave Repair by neighbourhood

Other repairs

Questions we get asked

Is a microwave worth repairing?

A switch, a latch, a fuse, a keypad or a waveguide cover, yes. A magnetron or a transformer on an older unit, usually not, and on a built-in trimmed into cabinetry the sum changes again because replacement means matching the opening. We give you both figures before you decide.

Can I open it and change the fuse myself?

Please do not. The capacitor inside holds a charge that can be lethal long after the unit is unplugged, and it has to be discharged deliberately before anything is touched. It is also the reason a blown fuse is a symptom worth diagnosing rather than a part worth swapping.

Why does the fan keep running after I open the door?

On over-the-range units the fan runs on to cool the magnetron and the cavity, and on some models it also responds to heat rising from the range below. A fan that never stops points at the thermostat that controls it, or at a control board stuck in the cooling state.

Do you work on built-in and drawer microwaves?

Yes, on the mainstream brands. Built-in units are the same electrically as a countertop machine, but they are trimmed into the cabinet and take longer to get out. Drawer models add a motor-driven opening mechanism, which is a common failure point in its own right.

The microwave sparked once and seems fine now. Do I need to do anything?

Yes. Arcing leaves a carbon track, and a carbon track gets worse every time the oven runs. Stop using it and have the cavity checked. Dealt with early it is usually the waveguide cover; left to burn through, it takes the magnetron and the repair stops being sensible.
